VECROS Daughter Board

Rs. 21,186.44 Rs. 16,949.15 Save 20%
Shipping calculated at checkout.

Pickup available at Vecros

Usually ready in 24 hours

Daughter Board  Compact Expansion Module for JetCore

Key Features:

  • Fully compatible with JetCore carrier board ecosystem
  • Dual MIPI CSI camera interfaces (2 × 2-lane) via 15-pin 1mm pitch FFC connectors
  • Full 40-pin GPIO header with I2C, I2S, UART, PWM, GPIO, SPI and Power support
  • Pinout aligned with NVIDIA Jetson developer kit standard for seamless integration
  • Wide operating temperature range from -40°C to +85°C for all-environment use
  • Ultra-compact at 86 × 67 mm and just 15g for weight-sensitive builds

Expand your JetCore platform effortlessly the Daughter Board  brings dual camera support and full GPIO flexibility in a lightweight module built for the edge.
Payment
American Express
Diners Club
Maestro
Mastercard
PayPal
RuPay
Visa

Overview:

The VECROS Daughter Board is a lightweight, compact add-on module built to extend the capabilities of the JetCore carrier ecosystem. Designed for seamless compatibility with JetCore, it brings dual CSI camera support and a full 40-pin GPIO interface fully aligned with the NVIDIA Jetson developer kit pinout making it the ideal expansion module for vision-based AI and sensor-rich robotic applications.

Whether you're adding stereo cameras for depth perception or connecting a range of sensors and actuators, the Daughter Board slots right into your JetCore stack with zero compatibility headaches.

Key Features:

  • Fully compatible with JetCore carrier board ecosystem
  • Dual MIPI CSI camera interfaces (2 × 2-lane) via 15-pin 1mm pitch FFC connectors
  • Full 40-pin GPIO header supporting I2C, I2S, UART, PWM, GPIO, SPI, and Power
  • Pinout aligned with NVIDIA Jetson developer kit standard for plug-and-play integration
  • Compact 86 × 67 mm form factor at just 15g for minimal footprint
  • Wide operating temperature range from -40°C to +85°C for industrial and outdoor use

The VECROS Daughter Board is a compact add-on module designed to seamlessly integrate with the JetCore carrier ecosystem. It expands the JetCore's capabilities by providing dual CSI camera connectivity and a 40-pin GPIO interface fully aligned with the NVIDIA Jetson developer kit pinout. Below are its key specifications.

Specification VECROS Daughter Board V2.0
Compatibility JetCore
MIPI CSI Interface 2 × 2-lane, 15-pin 1mm pitch FFC connector
40-Pin Header Interfaces I2C, I2S, UART, PWM, GPIO, SPI and Power
Pin Standard Jetson Developer Kit compatible pinout
Dimensions 86 × 67 mm
Weight 15g
Operating Temperature -40°C to +85°C

For setup tutorials and documentation, visit https://discuss.vecros.com/

No image available

Package Includes

  • 1 x VECROS Daughter Board
  • 1 x User Manual
